CNC angle punching machine
Quickly thread the pipe
Easy to operate, easy to learn and understand
12-15 thread ends can be processed per minute
Can save a lot of labor costs and economic costs
Thread end quality meets international standards, high pass rate, low loss
Introduction
The CNC Angle Punching Machine is a sophisticated piece of equipment designed to automate the process of punching holes in angle irons with exceptional precision and speed. This machine is a powerhouse in the metal fabrication industry, offering a solution that is both efficient and highly accurate. It stands as a testament to the advancements in CNC technology, which has made it possible to create complex patterns and designs in metal with ease.
The CNC Angle Punching Machine is more than just a tool; it's an enabler of innovation in metalworking. Its ability to punch holes with exacting precision allows for the creation of intricate metal components that are essential in a wide range of applications. From simple brackets to complex structural components, this machine is a versatile addition to any fabrication shop.
Technical Parameters
| Parameter | Specification |
|---|---|
| Punching Thickness | Up to 10mm |
| Punching Speed | Variable |
| Working Area | Variable by model |
| Machine Dimensions | Customizable |
| Power Supply | 220V/380V (Single/Three-phase) |
| Control System | Advanced CNC Controller |
Working Principle
Material Loading: The angle iron is securely loaded onto the CNC punching machine's worktable.
CNC Programming: The operator inputs the punching pattern and specifications into the machine's control system.
Punching Action: The CNC control system directs the punching head to the precise coordinates for each hole.
Precision Movement: The machine's servo motors ensure high-accuracy movement along multiple axes.
Cycle Completion: After all holes are punched, the machine returns to the home position, and the part is unloaded.
Features
Intelligent Adjustment: Automatically adjusts to the desired punching pattern and specifications.
Electric Actuation: Minimizes manual labor and increases the speed and safety of the punching process.
Efficiency: Reduces production time by automating the punching of multiple holes in a single setup.
Layout: A well-organized control panel and machine layout for ease of use and operation.
Safety and Reliability: Equipped with safety features and robust construction for dependable performance.
Adjustable Torque: Allows for the customization of punching force to accommodate different material thicknesses.
Automatic Return: The machine returns to the home position after completing a punching cycle, streamlining the workflow.
Application Scenarios
Construction: For punching holes in angle irons used in building frameworks and supports.
Gas Industry: Utilized for fabricating gas pipeline brackets and other supporting structures.
Petroleum: Employed in the production of metal components for oil rigs and refineries.
Chemical Processing: Ideal for punching holes in angle irons used in chemical plant construction.
Agriculture: Used in the manufacturing of metal components for agricultural machinery.
Marine: Essential for shipbuilding and the fabrication of metal structures for offshore platforms.
Equipment Composition
CNC Controller: The central control unit that manages all machine functions.
Punching Head: The component that performs the actual punching of holes in the angle iron.
Servo Motors: High-precision motors that drive the machine's movement along multiple axes.
Worktable: A sturdy and adjustable surface for holding the angle iron in place during punching.
Adjustment Mechanism: Allows for the fine-tuning of the punching head's position for accurate hole placement.
Safety Features: Includes emergency stop buttons and other safety interlocks to protect the operator.
Quality Control and Safety Standards
ISO Certification: Adherence to ISO 9001:2000 for a standardized approach to quality management.
Comprehensive Testing: Each machine undergoes rigorous testing to meet performance and safety criteria.
Quality Assurance: Ongoing checks throughout the manufacturing process to ensure CNC angle punching machine consistency.
Safety Features: Incorporation of safety mechanisms to protect the operator and prevent accidents.
Certifications: Holding certifications that validate compliance with international safety and quality standards.
After-Sales Service
Customer Support: Accessible and responsive support for all customer inquiries and concerns.
Warranty Program: Offering a comprehensive warranty that covers the machine against defects and malfunctions.
Maintenance Contracts: Providing maintenance contracts to ensure the machine remains in top condition.
Technical Support: Available to offer expert advice and support for any operational challenges.
Customized Solutions: Working closely with customers to develop solutions tailored to their specific needs.
Conclusion
For your angle iron punching needs, Hangzhou Yasda Trading Co., Ltd is your trusted partner. With a legacy of innovation and a steadfast commitment to quality, we offer a CNC Angle Punching Machine that is designed to exceed the expectations of professional buyers and global distributors. For more information or to discuss your specific requirements, please contact us at ysdthreadingmachine@gmail.com. Experience the difference that our CNC Angle Punching Machine can make in your projects.
